"D" Rubber Seal X109-HT - Sold by the CONTINUOUS YARD!

TRIM-LOK
SKU:
X109-HT
$6.95
Width:
1.00 (in)
Height:
1.00 (in)
Depth:
1.00 (in)
Current Stock:
5
Adding to cart… The item has been added
Description
Sold by the CONTINUOUS YARD
D-shaped Style EPDM Sponge Rubber Seal, with a height of .360" and a width of .610"
Tape: HT - General Acrylic PSA / This acrylic based adhesive is best used to hold the rubber seal in place while installed in a static application or compressed between two stationary objects
May be used in some light duty dynamic applications against a variety of substrates. Good heat performance -20F to +158F. Please Note: During application ambient temperature must be above 60° F.
Recommended temperature range for general applications: -20°F. through +150°F, Sponge Rubber (EPDM)
Application: For optimum performance - 25% - 50% maximum compression recommended
Resistance Ratings: Excellent resistance to water absorption, ozone, sunlight aging, low temperature, and compression set
Flammability and Code Compliance: FMVSS 302, UL 50
CLEANING AND APPLICATION INSTRUCTIONS
Regardless of bonding surface, it must be clean and free of surface contaminant such as oil, grease, mold release and dirt
Most bonding failures are due to improperly cleaned surfaces. Prior to applying any adhesive, Clean surface with 50/50 denatured alcohol and water solution
